TECHNICAL DATA
| Code | S400LV-1 |
| Description | Type 3 surge protection for power equipment |
| Test classification // EN type | III / T3 |
| Number of ports | One |
| Nominal voltage UN | 24 V AC (TN-S) |
| Nominal frequency | 50 Hz (60 Hz) |
| Maximum continuous operating voltage UC | 34 V AC / 34 V DC |
| Combination wave UOC | 2 kV |
| Protection level UP - L-N / L-PE / N-PE | ≤ 0,18 kV / ≤ 0,55 kV / ≤ 0,55 kV |
| Residual current IPE | ≤ 5 μA |
| Nominal discharge current In (8/20) μs | 1 kA |
| Short-circuit current rating ISCCR | 1,5 kA AC / 1 kA DC |
| Rated load current IL at 63 °C | 16 A AC |
| Max. backup fuse with branch wiring | 16 A AC (B) / 10 A DC (gG) / 10 A DC (B) |
| Maximum backup fuse for through wiring | 16 A AC (B) / 10 A DC (gG) / 10 A DC (B) |
| Ambient temperature (operation) | -40 °C ... 80 °C |
| Degree of protection | IP20 |
SHIPPING AND EXPORT INFORMATION
| PRODUCT CODE | S400LV-1 |
| GROSS WEIGHT kg | 0.105 |
| ORIGIN | DE |
| CN (Combined Nomenclature) | 85363030 |
| ECCN | EAR99 |
Manuels, prospectus
Installation Manuel
SHA256 Checksum:
975ff709958e7576f5cb5ba5bae5884b328606a4ad4c3f50c42a739f9b4426ce
SHA256 Checksum:
975ff709958e7576f5cb5ba5bae5884b328606a4ad4c3f50c42a739f9b4426ce
Multi
-
-
-
Certifications
Accessoires
Dear Customer, please note that our offices will be closed from December 24 to January 6 inclusive due to the winter holidays. The last shipping day before the break is Monday, 22nd. We kindly ask you to place any orders by December 18th. Orders received after this date may only be processed when operations resume on 7 January. Thank you for your cooperation.
Versions du produit
S400LV-1
SPD 34 VAC/44 VDC, TIPO III, CONT. FM, 3F.(L,N,PE)
Disponibilité à confirmer, nous contacter ?Accessoires
S400LV-1-RIC-SL
Replacement plug 24VAC / DC S400LV-1, with contact FM III / T3 24 VAC / DC
Disponibilité à confirmer, nous contacter ?
